Efficient pouch management

The automatic tension control (Auto Tension) supports a reliable automatic rolling.
You can also use the foot switch to adjust the rolling speed for manual operation.
Experience increased efficiency by connecting with ATDPS.

Detachable bobbin for efficient maintenance by patient or medicine

Detachable for storage and maintenance, bobbins are available in two sizes 400 mm and 500 mm as needed.
※ Bobbin is a round shape guide used for pouch strip rolling and is compatible with VIZEN, VIZEN DE, and WIZER.

User friendly control panel

The control panel is very intuitive and easy to use to set between automatic / manual mode,
forward (CW) winding / backward (CCW) winding as well as a preferred speed.


Product Spec

※ Product exterior and specifications are subject to change due to the company's research and development results without any prior notice.

Model JV-IR40
Dimensions(W*D*H) 400*410*920㎜
(With 400Ø bobbin)
Weight About 18㎏
MAX. Speed 80pack/min
(0~80 rpm Adjustable)
Control system MCU
Power consumption 22W
Power Supply 110 ~ 240V, 50/60㎐
Operation
Temperature/Humidity
0~40℃, 10~80%
