Automatic halving of tablets in various shapes

ez-CUT can automatically recognize different shapes (e.g. round, oval, rectangular)
without the need of tablet registration to perform fast cutting.
※ Restrictions may apply to select tablets. (tablets in special shapes, tablets smaller than 2 ㎜, soft tablets)

Fast & accurate tablet counting

Simple and intuitive operation using the control panel helps a fast and accurate tablet counting.

Separated collection cup for faulty tablets

Successfully halved tablets are dispensed into the collection cup on the right,
whereas tablets recognized as faulty (e.g. bad shapes, damaged tablets, unregistered shapes)
are automatically separated into the collection cup on the left.



Feature 03_EN.png


Hygiene maintenance

Halved tablets go straight into the collection cup without user’s manual intervention to keep the process clean and hygienic.


Product Spec

※ Product exterior and specifications are subject to change due to the company's research and development results without any prior notice.

Model

JV-EC10

Dimensions(W*D*H) 240*410*250㎜
Weight About 15㎏
Cutting Speed MAX. 20tablet/min
Counting speed 70tablet/min
MAX. Cutting size Round tablet(W*D) : 15*7㎜
Oval tablet(W*D*H) : 22*10*8㎜
MIN. Cutting size Round tablet(W*D) : 6*2㎜
Oval tablet(W*D*H) : 8*4*3㎜
MAX. Counting size 20*10*7㎜(W*D*H)
MIN. Counting size 6*3*2㎜(W*D*H)
Display and input LCD panel (192 x 64 Dots, blue/white)
Power consumption 5W(MAX. 80W)
Power Supply 110 ~ 240V, 50/60Hz
Operation
Temperature/Humidity
0~40℃, 10~80%
