Fast & accurate tablet counting

Each chute where medicines are released from has an LED indicator to inform the process status and chute location to
support fast and accurate tablet counting. Also, multiple types of medicines can be counted simultaneously to increase the productivity.

Door lock for enhanced security

An electric door lock enhances the security of costly medicines or special drugs which require strict control (such as narcotics).

Individually locked chute for safe operation

Operators can have access to chutes that are verified by barcode scanning only to prevent potential dispensing errors.

A compact design to minimize the footprint

The compact design with the width of just 540 ㎜ allows you to install it in a confined space and scale up to 10 units to maximize space efficiency.


Feature 04.png




Compatible with ATDPS (Multi Dose)

Canisters used for C-Cabin40 are compatible with ATDPS to support multi-dose packaging of medicines in various shapes,
as well as single-dose packaging.


Product Spec

※ Product exterior and specifications are subject to change due to the company's research and development results without any prior notice.

Model JV-CA40
Dimensions(W*D*H) 540*250*1,950㎜
Weight(Except canister) About 80㎏
Canister capacity 18EA
Maximum working rate MAX. 280tablet/min
Canisters capacity 230dram(850㎖) (Based on installing 4 canister extension tubes)
Chute capacity 60dram(222㎖)
Max. module connection 10EA
Operating system Windows XP SP3, MS .NET 4.0 or later
Control system PC, Micro Processor
Power consumption 180W
Power Supply 110 ~ 240V, 50/60Hz
Operation
Temperature/Humidity
0~40℃, 10~80%
Additional Option Automatic recognition of tablet location (ACRS)
DOT Matrix, Locking Door
